Fluke 375FC Digital Clamp Meter True RMS with 600A AC/DC Measures Capacitance and DC Current

Description

The Fluke 375 FC is an advanced True-RMS wireless AC/DC clamp meter engineered for high-performance industrial troubleshooting and predictive maintenance. Utilizing Original Engineering from Fluke, this diagnostic instrument provides precise measurements of non-linear signals through its True-RMS technology, ensuring data fidelity in complex electrical environments. The integration of Fluke Connect allows technicians to transmit, log, and trend measurement data wirelessly, isolating the operator from the arc flash zone while maintaining real-time system monitoring.

Technical Specifications:
Measurement Type: True-RMS AC/DC
AC Current Range (Jaw): 600 A
AC Current Range (iFlex): Up to 2500 A (probe optional)
DC Current Range: 600 A
AC/DC Voltage Range: 1000 V
Frequency Measurement: 500 Hz
Resistance Range: 60 kΩ
Capacitance Range: 1000 μF
Safety Rating: CAT IV 600 V / CAT III 1000 V
Jaw Opening: 34 mm
Operating Temperature: -10°C to +50°C
Dimensions: 249 x 85 x 45 mm
Weight: 395 g
Connectivity: Bluetooth (Fluke Connect)

Industrial Application:
The Fluke 375 FC is critical for plant maintenance engineers managing variable frequency drives (VFDs) and heavy-duty motor control centers. Its integrated low-pass filter and True-RMS capability allow for accurate voltage and current measurements on noisy, distorted signals typical of VFD outputs. By leveraging the 600A DC measurement capacity, it is equally indispensable for inspecting solar photovoltaic (PV) arrays, battery backup systems, and uninterruptible power supplies (UPS) in data centers.

Procurement and Lifecycle Value:
Technical Compatibility is guaranteed across standard industrial electrical architectures. This unit supports seamless integration with existing Fluke Connect ecosystems for comprehensive asset management. Standard Lead Time applies for global distribution, ensuring rapid deployment for critical facility upgrades or emergency replacement protocols.

Key Attributes
Max. Ac Current: 2500 A
Max. DC Current: 2500A
Measuring Voltage Range: 600V
Place of Origin: China
Model Number: 375
Brand Name: Fluke
Dimensions: 246 mm x 83 m x 43 mm
Display Type: Digital Only
Max. Ac Voltage: 600V
Max. DC Voltage: 600 V
Measuring Capacitance Range: 1000 uF
Measuring Current Range: 600A
Measuring Inductance Range: 1000 uF
Measuring Resistance Range: 60 kΩ
Operating Temperature: -14 to 122°F (10°C to 50°C)
Parameters Measured: DC Current, AC Voltage, DC Voltage, Capacitance, AC Current
Weight: 500g
AC Current via Jaw Range: 600.0 A
AC Current via Flexible Current Probe: 2500 A
DC Current Range: 600.0 A
AC Voltage Range: 600.0 V
DC Voltage Range: 600.0 V
Frequency via Jaw Range: 5.0 - 500.0 Hz
Resistance Range: 60 kΩ

Packaging and Delivery
Selling Units: Single item
Single package size: 30X20X15 cm
Single gross weight: 1.800 kg
