Fluke 709H Electronic Loop Calibrator with HART Communication

Description

The Fluke 709H Electronic Loop Calibrator is a high-precision diagnostic tool engineered for process control environments requiring integrated HART communication. Built upon Fluke’s Original Engineering standards, this device streamlines the calibration, troubleshooting, and maintenance of smart transmitters. It combines an intuitive rotary encoder interface with advanced HART modem capabilities, allowing technicians to perform fast, accurate mA measurements and HART device configurations without requiring a separate communicator.

Technical Specifications
Brand: Fluke
Model Number: 709H
Device Type: Precision Loop Calibrator with HART Communication
Current Measurement Range: 0 to 24 mA
Voltage Measurement Range: 0 to 30 V DC
Resolution: 1 µA (Current), 1 mV (Voltage)
Accuracy: 0.01% of reading ± 2 counts
Loop Power: 24V DC with selectable 250-ohm HART resistor
Operating Temperature: -10°C to 50°C
Storage Temperature: -20°C to 60°C
Power Supply: 6 x AAA alkaline batteries
Battery Life: ≥ 40 hours continuous use (measure mode)
Weight: 0.3 kg
Dimensions: 150 mm x 90 mm x 30 mm
Safety Certifications: CE, CSA C22.2 No. 61010-1
Ingress Protection: IP40

HART Communication Capabilities
The 709H provides comprehensive Technical Compatibility with universal and common practice HART commands. It allows users to read device tags, PV, and mA outputs directly from the transmitter. The built-in selectable 250-ohm resistor eliminates the need to carry external load resistors. The device supports DAC trimming, zero offset adjustments, and device configuration logging, significantly reducing diagnostic time on the plant floor.

Industrial Application
This calibrator is specifically designed for complex process automation scenarios, such as petrochemical refineries, pharmaceutical manufacturing, and water treatment facilities. In these environments, the 709H solves the critical problem of diagnosing smart valve positioners and pressure/temperature transmitters in confined spaces. Its compact architecture and rapid setup minimize downtime during scheduled outages or emergency troubleshooting.

Procurement and Lifecycle Value
Sourcing the Fluke 709H ensures long-term reliability and precise loop diagnostics. We optimize Lead Time for this critical instrumentation to ensure your maintenance teams are fully equipped without operational delays. The rugged construction and intuitive logic of the 709H guarantee a high return on investment by reducing the time required for loop testing and HART device commissioning.

Key Attributes
Type: Loop Calibrator
Place of origin: China
Customized support: OEM, ODM
Power: Loop Calibrator
Voltage: Other
Brand name: Fluke
Warranty: 1 years
Functions: MA source, mA simulate, mA read, mA read/loop power
Ranges: MA (0 to 24mA) and Volts (0 to 30VDC)
Accuracy: 0.01%
Operating Temperature Range: -10 to 55 °C (14 to 131°F)
Display: 128 x 64 pixels, LCD Graphic w/backlight, .34 high digits
Over-Voltage Protection: 240 VAC
Overload Current Protection: 28 mA DC
Power: Electronic

Packaging and Delivery
Selling Units: Single item
Single package size: 35X26X16 cm
Single gross weight: 2.300 kg
