Fluke Digital Multimeter Series 115C 116C 117C with True RMS Functionality

Description

The Fluke 110C Series (comprising the 115C, 116C, and 117C models) represents the pinnacle of compact, professional-grade digital multimeters engineered for demanding commercial, HVAC, and electrical troubleshooting. Featuring True RMS AC voltage and current measurement capabilities, these instruments ensure highly accurate readings even when analyzing non-linear loads and distorted signals.

INDUSTRIAL APPLICATION SCENARIO
In modern industrial automation environments, Variable Frequency Drives (VFDs) and switching power supplies introduce significant harmonic distortion into the electrical network. Standard averaging multimeters fail to measure these distorted waveforms accurately, often leading to false readings and delayed diagnostics. The Fluke 110C Series, with its True RMS functionality, resolves this critical issue by providing precise root-mean-square measurements of non-sinusoidal waveforms. For instance, the Fluke 117C utilizes LoZ low-impedance input technology to eliminate ghost voltages caused by stray coupling in adjacent conduits, preventing false positives during critical safety lock-out tag-out procedures. Meanwhile, the Fluke 116C integrates microamp measurements and direct temperature inputs to diagnose flame sensors and HVAC control circuits rapidly, minimizing system downtime.

TECHNICAL SPECIFICATIONS
Manufacturer: Fluke Corporation
Series Models: 115C, 116C, 117C
Measurement Type: True RMS
Display Count: 6000 counts, updates 4 per second
DC Voltage Range: 0.1 mV to 600 V
DC Voltage Accuracy: ±(0.5% + 2)
AC Voltage Range: 0.1 mV to 600 V (True RMS)
AC Voltage Accuracy: ±(1.0% + 3)
DC Amps Range (115C, 117C): 0.001 A to 10 A
AC Amps Range (115C, 117C): 0.001 A to 10 A (True RMS)
Microamps Range (116C): 0.1 µA to 600 µA
Resistance Range: 0.1 Ω to 40 MΩ
Capacitance Range: 1 nF to 9999 µF
Frequency Range: 0.01 Hz to 50 kHz
Temperature Measurement (116C): -40 °C to +400 °C
Safety Rating: CAT III 600 V
Certifications: CE, CSA, TÜV, VDE
Operating Temperature: -10 °C to +50 °C
Storage Temperature: -40 °C to +60 °C
Battery Type: 9 V Alkaline, typical 400 hours without backlight
Dimensions: 167 mm x 84 mm x 46 mm
Weight: 550 g

ENGINEERING AND LOGISTICS
Original Engineering: These instruments feature Fluke Original Engineering, ensuring robust build quality, drop-tested durability, and long-term calibration stability under harsh field conditions.
Technical Compatibility: Full Technical Compatibility with Fluke TL75 test leads, ToolPak magnetic hangers, and standard industrial current clamps.
Lead Time: Standard Lead Time for bulk commercial orders is 2 to 4 business days, subject to regional distribution stock levels.

Key Attributes
Measuring Current Range: 600.0 uA
Measuring Voltage Range: 600 V
Parameters Measured: Temperature (K), Low Input Impedance, DC Current, AC Voltage, Frequency, Temperature, DC Voltage, Capacitance, AC Current
Place of Origin: China
Model Number: 115C
Brand Name: FLUKE
Dimensions: 20*15*11cm
Feature: Data Logging, Dustproof, waterproof
Low Battery Indicator: Yes
Max. AC Current: 60 A
Max. AC Voltage: 600 V
Max. DC Current: 60 A
Max. DC Voltage: 600 V
Measuring Capacitance Range: 500uF
Measuring Inductance Range: ,
Measuring Resistance Range: 600 Ω
Operating Temperature: 14 to 122°F (-10 to 50°C)
Display Digital: 6,000 counts, updates 4/sec
Bar Graph: 33 segments, updates 32/sec
Battery: 9 V Alkaline

Packaging and Delivery
Selling Units: Single item
Single package size: 28X20X15 cm
Single gross weight: 2.000 kg
