Description
The Fluke Networks DSX2-5000 and DSX2-8000 DSX CableAnalyzer V2 series represent the industry standard for copper certification, testing, and troubleshooting. Built on the Versiv modular platform, these analyzers provide Original Engineering precision for network professionals deploying high-speed data infrastructure.
System Architecture & Integration:
The DSX2-5000 operates at a 1 GHz frequency, enabling Cat 6A and Class FA certification in just 10 seconds. The DSX2-8000 extends this capability to 2 GHz, supporting Cat 8 and Class I/II certification in 16 seconds. Both units integrate HDTDX (High Definition Time Domain Crosstalk) and HDTDR (High Definition Time Domain Reflectometry) to pinpoint fault locations precisely, ensuring optimal Technical Compatibility across diverse network topologies.
Technical Specifications:
Brand: Fluke Networks
Model Series: DSX2-5000 / DSX2-8000 (V2)
Equipment Type: DSX Cable Analyzer / Signal Generator
Frequency Range (DSX2-5000): 1 GHz
Frequency Range (DSX2-8000): 2 GHz
Test Speed (Cat 6A/Class EA): 10 seconds
Test Speed (Cat 8/Class I/II): 16 seconds
Supported Standards: TIA Category 5e, 6, 6A, 8 / ISO/IEC Class C, D, E, EA, F, FA, I/II
Display: 5.7-inch LCD with capacitive touchscreen
Battery Type: Lithium-ion battery pack (7.2 V)
Battery Life: 8 hours (typical operation)
Operating Temperature: 0 °C to 45 °C
Storage Temperature: -30 °C to 60 °C
Operating Humidity: 0% to 90% (0 °C to 35 °C)
Weight: 1.28 kg (main unit with module and battery)
Dimensions: 27.94 cm x 13.33 cm x 6.67 cm
Interfaces: RJ45, USB, Wi-Fi (via adapter)
Calibration Cycle: 1 Year
Industrial Application:
In hyper-scale data centers and enterprise IT environments, eliminating network latency and crosstalk is critical. The DSX2 series allows technicians to certify twisted-pair copper cabling for 10GBASE-T, 25GBASE-T, and 40GBASE-T deployments. By utilizing the ProjX management system, project managers can oversee multiple jobs simultaneously, ensuring zero errors in complex cable installations and verifying that all links meet stringent IEEE standards.
Procurement & Lifecycle:
Maintaining a reliable testing fleet requires predictable logistics. We offer an optimized Lead Time for these analyzers and their associated Versiv modules, ensuring your field teams remain equipped with fully calibrated, high-performance diagnostic tools.
Key Attributes
Amplitude resolution: 0.5 mV
Type: Cable Analyzer
Waveform: Square
Place of origin: United States
Frequency resolution: 1 Hz
Frequency (Hz): 2.4 GHz and 5 GHz
Brand name: Fluke
Customized support: OEM, ODM
Size: 28*15*11cm
Warranty: 1 years
Model number: DSX2-5000
Test Time CAT 6A / Class EA: 10 seconds
Internal Memory: Approximately 12,000 CAT 6A with plots
Adapter Channel: 1 GHz range
Plug type: Shielded RJ45
Display: 5.7" (14.47 cm) LCD display
Integrated Wi-Fi: Dual band (2.4 GHz and 5 GHz)
Material: Plastic
Packaging and Delivery
Selling Units: Single item
Single package size: 50X38X30 cm
Single gross weight: 5.000 kg
