Hioki DT4256 Digital Multimeter 60 MA to 10 a Direct Input

Description

The Hioki DT4256 is a highly versatile, True RMS digital multimeter engineered for complex industrial electrical testing and maintenance. Designed with Original Engineering standards, this unit provides precise direct current input measurement capabilities ranging from 60 mA to 10 A, ensuring Technical Compatibility across a wide spectrum of low to medium-power industrial control circuits. Available with an optimized Lead Time, the DT4256 delivers uncompromising accuracy in harsh environments, featuring robust drop-proof construction and advanced safety ratings.

Technical Specifications:
Manufacturer: Hioki
Model Number: DT4256
Measurement Method: True RMS
DC Voltage Range: 600.0 mV to 1000 V
AC Voltage Range: 6.000 V to 1000 V
DC Current Range: 60.00 mA to 10.00 A
AC Current Range: 600.0 mA to 10.00 A
Resistance Range: 600.0 Ohms to 60.00 MOhms
Capacitance Range: 1.000 uF to 10.00 mF
Frequency Range: 99.99 Hz to 99.99 kHz
Display Type: 4-digit LCD with bar graph, max 6000 digits
Display Update Rate: 5 times per second
Safety Category: CAT IV 600 V, CAT III 1000 V
Operating Temperature: -25 °C to 65 °C
Drop Proof: 1 meter onto concrete
Power Supply: LR03 alkaline batteries x 4
Dimensions: 84 mm W x 174 mm H x 52 mm D
Weight: 390 g

Industrial Application:
The Hioki DT4256 is critical for plant maintenance engineers troubleshooting variable frequency drives (VFDs) and automated PLC control panels. Its True RMS measurement capability ensures accurate voltage and current readings on distorted waveforms commonly found in inverter-driven motor circuits. The direct 10 A input allows technicians to safely measure load currents on secondary control loops without requiring external current clamps, streamlining diagnostics and minimizing equipment downtime in high-noise manufacturing environments.

Key Attributes
Measuring Current Range: 600.0 mA to 10.00 A
Measuring Voltage Range: 600 mV to 1,000 V
Place of Origin: Japan
Model Number: DT4256
Brand Name: Hioki
Dimensions: 52 x 84 x 174 mm
Measuring Capacitance Range: 1 nF to 100 mF
Measuring Inductance Range: 60 Ω to 600 MΩ
Measuring Resistance Range: 60 Ω to 600 MΩ
Operating Temperature: -10°C to 50°C
Product Name: Hioki Digital Multimeter
Model: DT4256
AC Voltage: 6 to 1,000 V,
DC Voltage: 600 mV to 1,000 V
Frequency: 99.99 Hz to 99.99 kHz
AC Current: 600.0 mA to 10.00 A, 3 ranges
Resistance: 600 Ω to 60 MΩ
Capacitance: 52 x 84 x 174 mm
Dimensions: -40°C to 800°C
Weight: 400g

Packaging and Delivery
Selling Units: Single item
Single package size: 28X18X11 cm
Single gross weight: 1.200 kg
