Description
The Honeywell BW MCXL-XWHM-Y GasAlertMicroClip XL is a highly advanced, multi-gas portable detector engineered for rigorous industrial safety applications. Designed to simultaneously monitor up to four atmospheric hazards, this device ensures continuous worker safety in hazardous environments. Utilizing Original Engineering from Honeywell, it delivers reliable, accurate, and tamper-proof gas detection with an extended battery life suited for demanding industrial shifts.
Technical Specifications
Brand: Honeywell BW Technologies
Model Number: MCXL-XWHM-Y
Product Series: GasAlertMicroClip XL
Housing Color: Yellow
Dimensions: 11.3 x 6.0 x 3.2 cm
Weight: 190 g
Operating Temperature: -20°C to +50°C
Operating Humidity: 0% to 95% RH (non-condensing)
Ingress Protection: IP68 (Waterproof up to 1.2m for 45 minutes)
Battery Type: Rechargeable lithium polymer
Battery Life: 18 hours (typical)
Recharge Time: < 6 hours
Alarm Type: Visual, vibrating, audible (95 dB)
Alarm Levels: Low, High, TWA, STEL, Over Limit (OL)
Pump Compatibility: Compatible with manual aspirator pump
Sensor Configuration & Measurement Ranges
Combustible Gases (LEL): 0-100% LEL (Resolution: 1%, Accuracy: ±5%)
Oxygen (O2): 0-30.0% vol (Resolution: 0.1%)
Hydrogen Sulfide (H2S): 0-100 ppm (Resolution: 1 ppm)
Carbon Monoxide (CO): 0-500 ppm (Resolution: 1 ppm)
Certifications & Approvals
CSA: Class I, Div. 1, Gr. A, B, C, D
ATEX: CE Ex II 1 G Ex ia IIC T4 Ga
IECEx: Ex ia IIC T4 Ga
CE: European Conformity
Industrial Applications
The MCXL-XWHM-Y is purpose-built for confined space entry, refinery turnarounds, and wastewater treatment operations. Its precise sensor architecture solves the critical problem of undetected atmospheric shifts in volatile environments. By providing real-time data on LEL, O2, H2S, and CO, it prevents exposure to toxic gases and mitigates explosion risks in petrochemical plants, maritime shipping holds, and underground utility vaults where gas accumulation per m³ can reach lethal concentrations rapidly.
Procurement & Lifecycle Value
Ensuring Technical Compatibility with the MicroDock II and IntelliDoX instrument management systems, this detector allows for automated bump testing, calibration, and comprehensive data logging. We provide optimized Lead Time for both single-unit replacements and bulk fleet deployments. Rely on the Original Engineering of Honeywell BW to maximize operational uptime, reduce maintenance overhead, and maintain strict compliance with global occupational safety standards.
Key Attributes
Type: Hydrogen Sulfide Combustible Gas Detector
Place of origin: China
Customized support: OEM, ODM
Model number: BW MCXL-XWHM-Y
Brand name: Honeywell
Material: Plastics
Power: Battery powered
Warranty: 1 years
Hydrogen Sulfide(H2S): 0 - 100 ppm
Carbon Monoxide(CO): 0 - 500 ppm
Oxygen(O2): 0 - 30.0%
Combustible Gases(LEL): 0 - 100% LEL 0-5.0% v/v
Size: 5.1 x 2.8 x 2.0 in. / 13.1 x 7.0 x 5.2 cm
Operating Temperature: -4 to 122°F / -20 to 50°C
Ratings Ingress Protection: IP66/67
Typical Battery Life: Recharges in 6 hours
Packaging and Delivery
Selling Units: Single item
Single package size: 29X21X15 cm
Single gross weight: 1.500 kg
