Description
The KAKU KA1806HA2 is a high-performance industrial-grade AC axial cooling fan engineered for continuous thermal management in high-density electrical enclosures, industrial automation cabinets, and heavy-duty power distribution systems. Built according to original engineering standards, this unit provides reliable forced-air convection to prevent thermal throttling and component failure in mission-critical hardware.
Technical Specifications:
Manufacturer: KAKU
Model Number: KA1806HA2
Product Type: AC Axial Fan
Rated Voltage: 220V – 240V AC
Frequency: 50 / 60 Hz
Input Power: 45W / 60W
Rated Current: 0.28A / 0.35A
Rotational Speed: 2600 / 2900 RPM
Airflow Volume: 10.2 / 11.5 m³/min (360 / 405 CFM)
Static Pressure: 147 / 176 Pa
Noise Level: 58 / 62 dBA
Bearing System: High-Precision Dual Ball Bearing
Motor Design: Shaded Pole / Capacitor-Run Induction Motor with Thermal Impedance Protection
Frame Material: Die-Cast Aluminum Alloy with Anti-Corrosion Coating
Impeller Material: PBT Thermoplastic (UL94V-0 Flame Retardant)
Insulation Class: Class B / Class F
Dielectric Strength: 1500V AC at 0.5mA 50/60Hz for 1 minute
Operating Temperature Range: -20°C to +70°C
Operating Lifetime (L10): 50,000 Hours at 25°C
Dimensions: 180 mm x 180 mm x 65 mm (Ø Mounting Hole: 4.5 mm)
Weight: 1.45 kg
Certifications: CE, RoHS, UL Component Recognized
Engineering Features & Performance:
– Aerodynamic impeller profile optimized for high static pressure against densely packed electronics.
– Heavy-duty aluminum housing acts as a secondary heat sink while resisting mechanical shock and vibration.
– Precision dual ball bearing architecture supports all-angle installation (horizontal, vertical, or tilted).
– Integrated thermal motor protection prevents winding burnout during locked-rotor conditions.
Industrial Application Scenario:
Optimized for installation in variable frequency drive (VFD) enclosures, high-power server racks, inverter cabinets, and CNC machine control units where sustained airflow is necessary to dissipate localized heat pockets and maintain system reliability in demanding factory environments.
Technical Compatibility and Lead Time:
This component ensures complete technical compatibility with standard 180 mm industrial cutouts and terminal power configurations. Original engineering build verification guarantees direct drop-in replacement for existing thermal management infrastructure. Standard procurement lead time is fast-tracked through authorized distribution networks to minimize operational downtime.
