$34.29

SKU: 676981899765 Brand:

Description

The KAKU KA2509HA2-2 is an industrial-grade thermal management solution engineered for high-static pressure environments. Unlike standard plastic-impeller fans, the all-metal construction ensures structural integrity under high thermal loads and prevents blade deformation during continuous operation. The dual ball bearing system is lubricated for life, providing a MTBF (Mean Time Between Failures) exceeding 50,000 hours at 40°C.

Manufacturer: KAKU
Model Number: KA2509HA2-2
Product Category: High-Performance Industrial Axial Fan
Construction: All-Metal Heavy Duty Design

Technical Specifications:
Dimensions: 254 x 254 x 89 mm
Rated Voltage: 220V AC
Frequency: 50/60 Hz
Input Power: 65/95 W
Rated Current: 0.35/0.45 A
Bearing Type: Dual High-Precision Ball Bearings
Rotational Speed: 2300/2100 RPM
Airflow Volume: 1000/850 m³/h
Static Pressure: 157/137 Pa
Noise Level: 68/65 dB(A)
Frame Material: Die-cast Aluminum Alloy with Black Anti-corrosion Coating
Impeller Material: Stainless Steel / Galvanized Sheet Steel
Insulation Class: Class B
Protection Rating: IP54 / IP55 equivalent
Operating Temperature Range: -20°C to +70°C
Termination: Lead Wire or Terminal Block Configuration
Weight: 2.5 kg

Industrial Application and Problem Solving:
This model is specifically designed for high-density server racks, CNC control cabinets, and large-scale power distribution units. Its 89mm depth allows for superior pressure development, making it ideal for pushing air through dense particulate filters or complex internal ducting where standard 38mm fans fail to maintain sufficient airflow. The clamp-fixed mounting system facilitates rapid installation and reduces vibration resonance in sheet metal enclosures.

Quality Assurance and Logistics:
Condition: 100% Original Engineering
Technical Compatibility: Direct replacement for standard 25489 series footprints
Lead Time: Immediate dispatch available for global MRO requirements
Warranty: 12-Month Manufacturer Standard Warranty
Certifications: CE, RoHS, UL Compliant

KA2509HA2-2 KAKU all-metal 25489/220V fan

KA2509HA2-2 KAKU all-metal 25489/220V fan

KA2509HA2-2 KAKU all-metal 25489/220V fan

KA2509HA2-2 KAKU all-metal 25489/220V fan

KA2509HA2-2 KAKU all-metal 25489/220V fan

KA2509HA2-2 KAKU all-metal 25489/220V fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
