New AFB0812SH 8025/12V Delta 0.51
New AFB0812SH 8025/12V Delta 0.51
New AFB0812SH 8025/12V Delta 0.51

New AFB0812SH 8025/12V Delta 0.51

$4.00

SKU: 700014624307 Brand:

Description

The Delta Electronics AFB0812SH is a high-performance DC axial cooling fan engineered for continuous thermal management in demanding industrial environments. Designed specifically for frequency inverters, variable frequency drives (VFDs), and high-density control cabinets, this 80x80x25mm unit delivers exceptional airflow and static pressure to prevent thermal throttling in critical electronic components.

Technical Specifications
Brand: Delta Electronics
Model Number: AFB0812SH (8025)
Frame Size: 80 x 80 x 25 mm
Rated Voltage: 12 VDC
Operating Voltage Range: 7.0 – 13.8 VDC
Input Current: 0.51 A
Power Consumption: 6.12 W
Rated Speed: 4000 ± 10% RPM
Maximum Airflow: 1.320 m³/min (46.62 CFM)
Maximum Static Pressure: 6.78 mmH2O
Acoustic Noise: 40.0 dB(A)
Bearing System: Precision Dual Ball Bearing
Housing Material: Thermoplastic PBT (UL 94V-0)
Impeller Material: Thermoplastic PBT (UL 94V-0)
Operating Temperature: -10°C to +60°C
Life Expectancy: 70,000 hours at 40°C
Weight: 80 g
Termination: Wire Leads
Safety Certifications: CE, CSA, UL, VDE

Industrial Application & Compatibility
This original engineering component is critical for maintaining optimal operating temperatures in industrial automation systems. The AFB0812SH is heavily utilized as a direct replacement part for high-capacity inverter cooling systems, ensuring seamless technical compatibility with existing thermal architectures. The precision dual ball bearing system guarantees extended lifecycle value, significantly reducing maintenance intervals in 24/7 operational facilities. With optimized lead time availability, this fan ensures minimal downtime for critical infrastructure requiring rapid and reliable thermal dissipation.

New AFB0812SH 8025/12V Delta 0.51

New AFB0812SH 8025/12V Delta 0.51

New AFB0812SH 8025/12V Delta 0.51

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
