$7.86

SKU: 683641165140 Brand:

Description

The SANJU SJ80025HA2 is an industrial-grade AC axial flow fan engineered for high-efficiency thermal management in compact electronic enclosures and control panels. Designed with a plug-in terminal architecture, this 80x80x25mm cooling fan delivers a large air volume to maintain optimal operating temperatures for critical internal components. Utilizing Original Engineering from San Ju Electric Machinery, the SJ80025HA2 ensures continuous, low-vibration operation in demanding environments.

Technical Specifications:
Brand: SANJU
Model Number: SJ80025HA2
Fan Type: AC Axial Flow Cooling Fan
Dimensions: 80 x 80 x 25 mm
Rated Voltage: 220V AC
Frequency: 50/60 Hz
Operating Voltage Range: 200V – 240V AC
Input Current: 0.07 A
Power Consumption: 14.0 W
Rotational Speed: 2500 / 3000 RPM ±10%
Maximum Airflow: 0.62 / 0.73 m³/min
Acoustic Noise: 32 / 36 dB(A)
Connection Type: Plug-in Terminal (2-pin)
Bearing System: Precision Ball Bearing
Weight: 250 g

Material & Environmental Profile:
Frame Material: Die-cast Aluminum Alloy (Black painted for corrosion resistance)
Impeller Material: Thermoplastic PBT (UL94V-0 flammability rating)
Operating Temperature: -10°C to +70°C
Storage Temperature: -40°C to +85°C
Dielectric Strength: 1500V AC for 1 minute
Insulation Resistance: 500V DC, 100M Ohm minimum
Certifications: CE, RoHS, UL compliant

Industrial Application:
This high-velocity cooling fan is specifically designed for integration into CNC machine control cabinets, telecommunication racks, and industrial power supply units. The SJ80025HA2 resolves critical localized overheating issues by providing rapid heat dissipation in confined spaces, thereby preventing thermal throttling of sensitive microprocessors and power relays.

Procurement & Lifecycle Value:
Technical Compatibility is guaranteed for direct replacement in existing 8025 AC fan slots, minimizing system downtime. The plug-in terminal design allows for rapid hot-swapping during routine maintenance. Contact our distribution network for current Lead Time and volume pricing on this authentic SANJU component.

SJ80025HA2 SANJU 8025/220V fan

SJ80025HA2 SANJU 8025/220V fan

SJ80025HA2 SANJU 8025/220V fan

SJ80025HA2 SANJU 8025/220V fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
