$12.86

SKU: 895436925718 Brand:

Description

The NMB Technologies 4710PS-22T-B30 is an industrial-grade AC axial compact fan engineered for high-reliability thermal management across enclosed automation cabinets, variable frequency drives (VFDs), and power conversion systems. Designed with original engineering integrity, this unit integrates a rugged aluminum die-cast frame with precision dual ball bearings to ensure extended MTBF and consistent aerodynamic throughput in demanding factory floor environments.

TECHNICAL SPECIFICATIONS
Manufacturer: NMB Technologies (MinebeaMitsumi)
Model Number: 4710PS-22T-B30
Frame Dimensions: 119 mm x 119 mm x 25 mm
Rated Voltage: 220V / 230V AC
Operating Voltage Range: 180V to 240V AC
Frequency: 50 / 60 Hz
Input Power: 14.0 W (at 60 Hz) / 15.0 W (at 50 Hz)
Rated Current: 0.08 A to 0.09 A
Nominal Speed: 2600 RPM (50 Hz) / 2900 RPM (60 Hz)
Airflow Rate: 1.80 m³/min / 65.0 CFM (50 Hz) to 2.12 m³/min / 75.0 CFM (60 Hz)
Static Pressure: 34.3 Pa / 0.14 in H2O (50 Hz) to 43.1 Pa / 0.17 in H2O (60 Hz)
Acoustic Noise Level: 37.0 dBA (50 Hz) / 40.0 dBA (60 Hz)
Bearing Type: Precision Dual Ball Bearings
Motor Structure: Shaded Pole Induction Motor
Motor Protection: Impedance Protected
Housing Material: Die-Cast Aluminum (Black Coating)
Impeller Material: Thermoplastic PBT (UL94V-0 Rated)
Termination: Faston Terminal Lugs (2-Pin)
Operating Temperature Range: -10°C to +70°C
Storage Temperature Range: -40°C to +70°C
Expected Service Life: 50,000 Hours (L10 at 25°C)
Weight: 490 g
Certifications: UL, CSA, VDE, CE, RoHS Compliant

APPLICATION & TECHNICAL COMPATIBILITY
Technical Compatibility is optimized for critical thermal zones within industrial power cabinets, server racks, CNC controllers, and high-capacity inverter equipment. The 25 mm slim profile allows seamless integration into compact chassis configurations where space constraints prevent the use of standard 38 mm fans, resolving local hot-spot accumulation and safeguarding power semiconductors (IGBTs) against thermal throttling and component degradation.

AVAILABILITY & PROCUREMENT
Condition: 100% Brand New Surplus Stock (Unused, fully functional, factory original)
Original Engineering: Authentic NMB Minebea factory specification
Lead Time: Immediate dispatch from available warehouse inventory

4710PS-22T-B30 NMB 220V fan

4710PS-22T-B30 NMB 220V fan

4710PS-22T-B30 NMB 220V fan

4710PS-22T-B30 NMB 220V fan

4710PS-22T-B30 NMB 220V fan

4710PS-22T-B30 NMB 220V fan

4710PS-22T-B30 NMB 220V fan

4710PS-22T-B30 NMB 220V fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
