The ADDA AB06012UB-D0B is a high-performance DC centrifugal blower engineered for precision thermal management in compact electronic enclosures. Utilizing a 4-wire PWM interface, this turbo fan delivers dynamic speed regulation, allowing automated systems to optimize cooling efficiency based on real-time thermal loads. Built to Original Engineering standards, it ensures maximum Technical Compatibility with demanding industrial control systems.

Technical Specifications
Manufacturer: ADDA Corporation
Model Number: AB06012UB-D0B
Fan Type: Centrifugal Blower / Turbo Fan
Dimensions: 60 x 60 x 15 mm
Operating Voltage: 12V DC
Bearing System: Dual Ball Bearing
Speed Control: 4-Wire PWM (Pulse Width Modulation)
Speed (Max): 5500 ± 10% RPM
Airflow: 6.5 CFM
Static Pressure: 0.45 inH2O
Acoustic Noise: 42.0 dB(A)
Current Rating: 0.30 A
Power Consumption: 3.6 W
Operating Temperature: -10°C to +70°C
Weight: 35 g
Housing Material: UL94V-0 Thermoplastic
Impeller Material: UL94V-0 Thermoplastic
Termination: 4-Pin Wire Lead (Power, Ground, Tachometer, PWM Signal)

Industrial Application
The AB06012UB-D0B is specifically designed for integration into high-density server racks, telecommunications equipment, and automated optical inspection (AOI) machinery. In these environments, localized heat generation can compromise sensitive microprocessors. The centrifugal airflow design channels air at a 90-degree angle, making it ideal for low-profile chassis cooling where standard axial fans cannot operate effectively. The precise PWM control loop ensures that the fan scales its output to match thermal demands, reducing overall acoustic noise and extending the operational lifespan of both the fan and the host equipment. Standardized manufacturing guarantees a predictable Lead Time for bulk procurement and maintenance cycles.

AB06012UB-D0B New ADDA 6015 fan

AB06012UB-D0B New ADDA 6015 fan

AB06012UB-D0B New ADDA 6015 fan

AB06012UB-D0B New ADDA 6015 fan

AB06012UB-D0B New ADDA 6015 fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
