Description
The Fluke 923 and Fluke 925 represent the industry standard for precision HVAC diagnostics, environmental monitoring, and ventilation system balancing. Engineered to deliver high-accuracy velocity, volume flow, and temperature readings, these instruments ensure compliance with international building performance and occupational safety standards. The Fluke 923 utilizes hot-wire technology for high-sensitivity measurements in confined ductwork, while the Fluke 925 employs a robust mechanical vane for high-volume laminar flow assessments at diffusers and grilles.
FLUKE 923 TECHNICAL SPECIFICATIONS
Measurement Technology: Thermal Hot-Wire / Thermistor
Air Velocity Range: 0.2 m/s to 20.0 m/s
Air Velocity Resolution: 0.1 m/s
Air Velocity Accuracy: ±(5% of reading + 0.1 m/s)
Temperature Range: 0 °C to 50 °C
Temperature Accuracy: ±1.0 °C
Probe Design: Telescopic probe up to 1.0 m length
Power Supply: 4 AA alkaline batteries
Display: Segmented LCD with backlight
FLUKE 925 TECHNICAL SPECIFICATIONS
Measurement Technology: Rotating Vane (70 mm diameter)
Air Velocity Range: 0.4 m/s to 25.0 m/s
Air Velocity Resolution: 0.01 m/s
Air Velocity Accuracy: ±2% of full scale
Airflow Range: 0 to 99,999 m³/hr
Temperature Range: 0 °C to 50 °C
Temperature Accuracy: ±0.8 °C
Weight: 363 g
IP Rating: IP40 protection
INDUSTRIAL APPLICATION SCENARIO
In pharmaceutical cleanroom validation and complex HVAC commissioning, precise laminar flow control is critical to prevent cross-contamination. The Fluke 923 solves the challenge of measuring low-velocity air currents inside narrow duct geometries where standard vane sensors cannot fit, utilizing its telescopic hot-wire probe. Conversely, the Fluke 925 is deployed at the supply and return grilles to measure total volumetric flow rates, ensuring the HVAC system meets the specified air exchange rates.
PROCUREMENT AND LOGISTICS
Original Engineering: 100% authentic Fluke instrumentation with factory calibration certificates traceable to international standards.
Technical Compatibility: Fully compatible with standard HVAC testing protocols, building management systems (BMS) verification workflows, and environmental compliance audits.
Lead Time: Standard dispatch within 3 to 5 business days from global distribution hubs. Express shipping options available for critical facility shutdowns.
Key Attributes
Resolution: 0.001 m/s
Temperature Range: -20℃ - 60℃
Type: Vane Anemometer
Place of Origin: China
Material: ABS
Starting Wind Speed: 0.1 m/s
Wind Speed Unit Selection: OBM
Packaging: Plastic Box
Model Number: 923
Brand Name: Fluke
Wind speed measurement Range: 0.20 m/s - 20.00 m/s, 40 fpm - 3940 fpm
Display: Dual-screen 4-digit (9999 points) LCD screen
Wind speed: Ft/m; m/s
Dimensions: 181 x 71 x 38 mm
Weight: 400g
Packaging and Delivery
Selling Units: Single item
Single package size: 48X27X16 cm
Single gross weight: 2.500 kg
