$12.86

SKU: 680429685197 Brand:

Description

The NMB-MAT 4715MS-10T-B50 is a high-performance industrial axial cooling fan engineered for continuous duty in demanding thermal management environments. This 120mm AC fan is specifically designed for CNC machinery, airport infrastructure, and server enclosures where high static pressure and reliability are critical.

Technical Specifications:
Manufacturer: NMB Technologies (MinebeaMitsumi)
Model Number: 4715MS-10T-B50
Frame Size: 120mm x 120mm x 38mm
Bearing Type: Dual Precision Ball Bearing
Input Voltage: 100V AC
Frequency: 50/60 Hz
Input Power: 15.0 W / 14.0 W
Rated Current: 210 mA / 180 mA
Rotational Speed: 2600 RPM / 2900 RPM
Airflow Capacity: 88.2 CFM / 102.0 CFM (2.50 m³/min / 2.90 m³/min)
Static Pressure: 63.7 Pa / 84.3 Pa
Noise Level: 37 dB / 41 dB
Termination: Faston #110 terminals (Quick Connect)
Frame Material: Aluminum Die-Cast
Impeller Material: Polycarbonate (Glass Fiber Reinforced, UL94V-0)
Operating Temperature: -10°C to +70°C
Expected Life: 50,000 Hours (L10 at 25°C)
Weight: 490g

Engineering Logic and Construction:
The 4715MS series utilizes a shaded pole induction motor housed within a robust aluminum frame to provide superior heat dissipation and structural integrity. The dual ball bearing system ensures Technical Compatibility with both horizontal and vertical mounting orientations without compromising the lifecycle. The glass-fiber reinforced impeller is aerodynamically optimized to maintain high airflow-to-noise ratios in high-impedance systems.

Industrial Application:
This unit is a critical component for CNC control cabinets and airport electronics systems where dust accumulation and heat spikes can lead to system failure. The 100V AC configuration is optimized for specialized power grids found in Japanese-spec industrial equipment and specific aviation ground support hardware. Replacing worn units with this Original Engineering component ensures the maintenance of factory-specified thermal gradients.

Logistics and Quality Assurance:
Condition: Brand New, Original NMB Authentic
Lead Time: Immediate dispatch available for standard inventory levels
Compliance: UL, CSA, VDE, CE Certified
Quality Guarantee: Genuine product verification with full manufacturer traceability

New NMB fan 4715MS-10T-B50 CNC fan

New NMB fan 4715MS-10T-B50 CNC fan

New NMB fan 4715MS-10T-B50 CNC fan

New NMB fan 4715MS-10T-B50 CNC fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
