GOLDTOOL TCT-1620 5 in 1 Network Tester RJ-45/RJ-11/BNC/1394/USB Cable Electronic Power

$43.00

SKU: 1600988791082

Description

The GOLDTOOL TCT-1620 is a professional-grade handheld diagnostic instrument engineered for verification, pinout mapping, and fault identification across structured industrial cabling plants. Utilizing a split-chassis design with a detachable master and remote transceiver unit, the TCT-1620 delivers precise point-to-point continuity validation across five distinct physical interface topologies: RJ-45 (8P8C), RJ-11/RJ-12 (6P4C/6P6C), BNC coaxial, USB 2.0 (Type A and B), and IEEE 1394 FireWire (6-pin). Built with original engineering standards for mission-critical infrastructure maintenance, the unit provides automated sequential scanning to detect open circuits, conductor shorts, crossed pairs, miswires, and shield grounding integrity in installed or patch-cord configurations.

Technical Specifications
Brand: GOLDTOOL
Model Identifier: TCT-1620
Device Classification: 5-in-1 Multi-Interface Continuity and Wire-Map Tester
Primary Interface Formats: RJ-45, RJ-11, RJ-12, BNC, USB (Type A/B), IEEE 1394 FireWire (6-Pin)
Diagnostic Fault Detection: Open Circuit, Short Circuit, Reversed Pair, Crossed Wires, Split Pairs, Shield Continuity
Coaxial Impedance Handling: 25 Ω / 50 Ω BNC Terminator Indication
Testing Method: Master-to-Remote sequential loopback scanning and single-end modular check
Maximum Cable Run Distance: 300 m (1000 ft)
Status Display: Low-power LED array (Pin-by-Pin status, BNC terminator, Connection status, Low Battery)
Audible Alert: Integrated piezoceramic tone generator for pass/fail confirmation
Power Supply: Standard 9V DC alkaline battery (NEDA 1604 / 6LR61)
Operating Supply Current: < 25 mA
Housing Construction: High-density impact-resistant ABS thermoplastic
Chassis Configuration: Main unit with slide-locking detachable remote module
Operating Temperature Range: 0 °C to 50 °C
Storage Temperature Range: -20 °C to 65 °C
Relative Humidity: 10% to 85% RH (non-condensing)
Dimensions: 200 mm x 100 mm x 27 mm
Weight: 230 g (excluding power cell)
Compliance: CE, RoHS

Operational Architecture and Pinout Validation
The TCT-1620 deploys micro-powered diagnostic logic across the pin configurations of each connector family. During automatic scan routines, the master unit sequences test voltages across each line while the remote terminator returns pinout topology states. The multi-segment LED matrix provides immediate visualization of individual line states, distinguishing between direct 1:1 continuity, cross-wired pairs (Ethernet T568A/B vs crossover), and structural breaks. Shield grounding detection validates the continuous drain wire in STP/FTP data cables, ensuring interference rejection in electrically noisy factory automation environments. For coaxial networks, the BNC port provides direct feedback on core conductor continuity, ground shield status, and terminating resistance.

Industrial Deployment and System Integration
The GOLDTOOL TCT-1620 is designed for field technicians, system integrators, and industrial network engineers maintaining converged control cabinets, SCADA interfaces, building management systems (BMS), and legacy fieldbus links. The split remote enables single-operator testing of pre-routed cables across patch panels, wall plates, conduit terminations, and remote field junction boxes. The dual support for legacy IEEE 1394, legacy BNC telemetry, universal USB interfaces, and standard telecom/Ethernet lines reduces the need for multiple specialized test sets during plant commissioning and preventive maintenance.

Procurement and Technical Compatibility
Technical Compatibility: Direct pin-level compatibility with Cat3, Cat5, Cat5e, Cat6, Cat6a UTP/STP, RJ-11/RJ-12 voice lines, 50 Ω/75 Ω BNC coaxial CCTV/telemetry, USB 1.1/2.0 lines, and IEEE 1394 industrial vision cables.
Standard Package Contents: TCT-1620 Main Unit, Detachable Remote Module, BNC Terminator Plug, Protective Carrying Pouch, Operation Manual.
Lead Time: In-stock standard dispatch available within 24 to 48 hours for global B2B procurement; volume factory orders subject to standard manufacturer allocation schedules.

Key Attributes
Type: Cable tester
Place of origin: China
Customized support: OEM, ODM
Power: RJ- 45 / RJ-11 / BNC / 1394 / USB
Protection Class: IP65
Voltage: Other
Brand name: GOLDTOOL
Warranty: 1 years
Model: TCT-1620
Detection type: RJ- 45 / RJ-11 / BNC / 1394 / USB
Inspection scope 1: Continuity, wiring errors,
Inspection scope 2: Open circuit, short circuit,
Inspection scope 3: Crossover and Ground
Function 1: LED prompt
Function 2: Sound prompts test results
Power: Electronic

Packaging and Delivery
Selling Units: Single item
Single package size: 28X16X11 cm
Single gross weight: 1.500 kg
