Description
The Siglent SSA3021X Plus is a high-performance spectrum analyzer engineered for advanced RF measurement, EMI pre-compliance testing, and signal analysis. Built upon Original Engineering standards, this unit integrates a 2.1 GHz frequency range with a built-in tracking generator and preamplifier, providing exceptional sensitivity and dynamic range for complex RF environments.
Technical Specifications:
Frequency Range: 9 kHz to 2.1 GHz
Resolution Bandwidth (RBW): 1 Hz to 1 MHz
Displayed Average Noise Level (DANL): -161 dBm/Hz (Typical)
Phase Noise: <-98 dBc/Hz at 1 GHz, 10 kHz offset
Total Amplitude Accuracy: < ±0.7 dB
Tracking Generator Frequency: 100 kHz to 2.1 GHz
Display: 10.1-inch capacitive multi-touch screen (1024×600 resolution)
Interfaces: USB Host, USB Device, LAN, HDMI
Operating Temperature: 0 °C to 50 °C
Dimensions: 393 mm x 207 mm x 116.5 mm
Weight: 4.60 kg
System Architecture and Integration:
The SSA3021X Plus features a robust digital IF technology architecture that ensures reliability and measurement precision. It supports extensive Technical Compatibility through standard SCPI command sets, allowing seamless integration into automated testing environments via USB or LAN. The inclusion of a web browser remote control interface facilitates remote monitoring and data acquisition in distributed laboratory setups.
Industrial Application:
This testing equipment is critical for electronics manufacturing and R&D facilities requiring rigorous EMI pre-compliance diagnostics and RF transmitter characterization. By utilizing the integrated tracking generator and preamplifier, engineers can perform precise filter and amplifier frequency response measurements, significantly reducing troubleshooting time during the product development cycle.
Procurement and Lifecycle Value:
Designed for continuous operation in demanding industrial laboratories, the SSA3021X Plus ensures long-term calibration stability. We provide accurate Lead Time estimates for this instrument to support your project scheduling and facility upgrade requirements.
Key Attributes
Type: Tracking Generator
Accuracy: < 0.7 dB
Place of origin: China
Customized support: Software Reengineering
Power: 9KHz-2.1GHz
Protection Class: IP65
Voltage: 100 to 240V
Brand name: Siglent
Application: Research and development
Warranty: 1 years
Frequency Range: 9 kHz~2.1 GHz
Resolution Bandwidth: 1 Hz~1 MHz
Displayed Average Noise Level: -161 dBm/Hz
SSB Phase Noise: < -98 dBc/Hz
Third-order intercept: +10 dBm
Tracking Generator: 100kHz~2.1GHz
Modulation Analysis: AM, FM; ASK, FSK, MSK, PSK, QAM
Packaging and Delivery
Selling Units: Single item
Single package size: 48X37X29 cm
Single gross weight: 4.000 kg
